Produktbeschreibung Produktbeschreibung Funktionsbeschreibung Der TURCK USB-2-IOL-0002 ist ein IO-Link-Master gemäß IO-Link-Spezifikation 1.1. Mit dem USB-fähigen IO-Link- Master lassen sich IO-Link-Devices z. B. über einen PC via FDT/DTM parametrieren. Bestimmungsgemäße Verwendung Der TURCK IO-Link-Master kann ausschließlich zur Parametrierung von IO-Link-Devices und zum Ein-/Auslesen von Daten über einen PC genutzt werden.
Die USB-B-Schnittstelle sorgt für einen einfachen Anschluss an einen PC. Das für die Inbetriebnahme notwendige Softwarepaket, bestehend aus Treiber und DTM, steht unter www.turck.com zum Download bereit. Das IO-Link-Device wird an den M12 x 1-Port angeschlossen und wird über die USB-Schnittstelle mit Energie ver- sorgt.
Das Gerät wird mit Anschluss an einen PC sowie ggf. eine Stromquelle sofort in Betrieb genommen. Zur Paramet- rierung der angeschlossenen IO-Link-Devices benötigen Sie die Softwarekombination aus FDT-Rahmenapplikati- on (z. B. PACTware ) und dem DTM (Device Type Manager). Hans Turck GmbH & Co. KG • Tel. +49 208/4952-0 • Fax +49 208/4952-264...
Das Gerät ist nicht zur Reparatur durch den Benutzer bestimmt. Sollte das Gerät defekt sein, nehmen Sie es außer Betrieb und schicken Sie es zurück an TURCK. Beachten Sie dabei die mit Lieferung vereinbarten Garantiebedin- gungen. außer Betrieb nehmen Beenden Sie die Softwareverbindung zwischen IO-Link-Master und IO-Link-Device.
Operating modes Functional principle Accessories installation connection Connection USB port Connection IO-Link Connection plug-in power supply commissioning operation Maintenance repair take out of service Disposal technical data Hans Turck GmbH & Co. KG • Tel. +49 208/4952-0 • Fax +49 208/4952-264...
IO-Link master you can parametrize IO-Link devices via PC with the FDT/DTM frame application PACTware™. Intended use The TURCK IO-Link master can only be used for parametrizing IO-Link devices and for reading/writing of data via PC. The device cannot be used for data exchange with a parent bus system or a PLC.
Device description The 1-channel TURCK IO-Link master is connected to a PC via the USB-B port and controls the communication with the connected IO-Link device. The device meets the IO-Link specification 1.1. Compared to version 1.0, the IO-Link master V1.1 has also the fol- lowing properties: ■...
Easily connected to PC USB port. The necessary software package for the commissioning, consisting of driver and DTM, is ready for download under www.turck.com. The IO-Link device is connected to the M12 x 1 port and powered via the USB port. In the event of increased cur- rent consumption (> 80 mA), use the external plug-in power supply.
Manager). Please read the instructions for installation of the software, "Getting started - FDT/DTM Frame PACTware™ with IO-Link" (D102037). It is available for download on www.Turck.de/products. Hans Turck GmbH & Co. KG • Tel. +49 208/4952-0 • Fax +49 208/4952-264...
The device is not intended for repair by the user. If the device should be defective, take it out of service and send it back to TURCK. Please pay attention to the warranty conditions agreed with delivery. take out of service Stop the software communication between IO-Link master and IO-Link device.
Seite 14
