Damper control unit for smoke control areas
A
SECTION A-A
30
A
DETAIL B
SCALE 1 : 2
SCALE 1 : 2
DETAIL D
SCALE 1 : 2
Bracket and screw
DETAIL E
OPEN
The Bracket make the secondary air open with ca. 40%
If you change the direction of the bracket the
secondary air will be open with ca. 30%.
Bracket and screw
Material:
Jegstrupvej 60
DK 8361 Hasselager
PROPRIETARY AND CONFIDENTIAL. The information contained in this drawing is the sole property of TermaTech AS.
Any reproduction in part or as a whole without the written permission of TermaTech AS i prohibited.
DETAIL C
Bracket and screw
SCALE 1 : 2
Scale: Tegningsnr. / emnenavn:
40102 TT20 Stove assy - smoke - GB
1:10
Title:
TT20 Stove assy - smoke -GB
Model:
TT20
Revision
25. april 20
Created da
25. april 20
Initialer:
EMN
