Product specifications
LCD display
46 cm measured diagonally
TFT LCD module
Resolution (max.)
SXGA 1280 x 1024 pixels
Displayable colors (max.)
Approx. 16.77 million colors (8 bit)
Brightness (max.)
250cd/m
Dot pitch
0.2805(H) 0.2805(V) mm
Contrast ratio
350:1
Angle of visibility
Left-right 160°; Up-down 160°
Screen display size
Horizontal 359 mm x Vertical 287.2 mm
Video signal
Analog: Analog RGB (0.7Vp-p) [75Ω]
Digital: DVI standard based on 1.0
Sync signal
Separate Sync (TTL level: +/-), Sync on
Green, Composite Sync (TTL level: +/-)
Expansion compensation
Digital screening
Enlarging VGA/SVGA/XGA etc. with a
compensation process. (no enlarging, based on a
fixed aspect ratio, and enlarging to full screen size.)
Plug & Play
VESA DDC2B compatible
Power management
VESA: based on DPMS
DVI: based on DMPM
Input signal terminal
Analog:
Digital / Analog: 29 pin DVI-I
Speaker output
1W + 1W
Audio input terminal
Mini stereo jack
Headphone terminal
Mini stereo jack
Height adjustment
Adjustment range: Approx. 80 mm
Screen rotation
Clockwise 0 - 90°
Screen tilt
Upward approx. 0 -30°; downward approx. 0 - 5°
Screen swivel
Approx. 90° from left through right
Power supply
AC100 - 240V, 50/60Hz
Temperature of operating environment
5 - 35°C
Downloaded from www.Manualslib.com
2
15 pin mini D-sub (3 rows)
manuals search engine

Specifications

Power consumption
51W (With no audio input)
(55W maximum, 5W when in power-saving
mode)
Dimensions (W x D x H) (Units: mm)
With long width screen:
With long heightscreen: 324 x 213 x 463 - 543
Weight
Approx. 8.7 kg
Display area only, approx. 5.5kg
Dimensions
- Analog signal cable: Approx. 2.0m
- Audio cable: Approx. 2.0m
- Digital signal cable, NL-C01E (purchased
separately): Approx. 2.0m
- Analog signal cable, NL-C02E (purchased
separately): Approx. 2.0m
- 2-input cable, NL-C03J (purchased
separately): Approx. 0.25m
27
395 x 213 x 427 - 507
(Units: mm)
395
277
324
213
