O S D
N- CREEN ISPLAY
This LCD monitor features an On-Screen Display (OSD) menu. These
icons are designed to make your monitor display settings easier. When
highlighted, the icons illustrate the control function to assist you in
identifying which control needs adjustment.
Before activating the OSD menu, the Auto button (3) can be used to
automatically adjust the display to the proper size and horizontal and
vertical position. (Press button for 2 seconds.)
The OSD menu activates automatically when you press the
Menu button (1) on the front of the monitor. The OSD remains centered
on the screen while you make your adjustments. Use either the
or select button (2) to move the highlight to your selection. Pressing
menu button (1) the submenu will appear nearby main menu. Press Menu
button (1) and release again, the highlight of adjusted items and scroll bar
will change the color from black to blue. Use the
button (2) to adjust the control.
When you have finished making adjustments, press the menu button (1)
to save settings. The scroll bar will change to black. You can select other
function to make adjustment. Also you can select EXIT icon and press
menu button (1) to go back to main menu.
6
or select
M D
ENU ESCRIPTIONS
Main Menu
C
ONTRAST
This control allows you to make adjustments to the contrast of the
display screen.
B
RIGHTNESS
Selecting this control allows you to make adjustments to the luminosity
level of the display screen.
H-P ( )
OSITION HORIZONTAL POSITION
Select this control and then use the
center the image horizontally on the screen.
V-P ( )
OSITION VERTICAL POSITION
Select this control and then use the
to center the image vertically on the screen.
H-S ( )
IZE HORIZONTAL SIZE
Select this control and then use the
expend or decrease the image width to horizontally fill the display screen.
and select buttons (2) to
and select buttons (2)
and select buttons (2) to
