Equipment Checklist; Monitor Features - Miro TD271 Handbuch

E C
QUIPMENT HECKLIST
Before operating your display, please check to make sure that all of the
items listed are present in your package:
• Color TFT LCD Monitor
• Accessory Box:
1. AC to DC Adapter & Power Cord
2. Signal Cable 15-pin D-Sub
3. Audio cable
4. This manual
Note : If any item(s) are missing or damaged, contact your dealer
immediately.
Remove the monitor from its shipping carton.
Save the carton and packaging materials in case you need to relocate the monitor.
2
M F
ONITOR EATURES
* Supports Analog IBM compatible PC, Apple Macintoch
* VESA Display Data Channel (DDC) 1/2B compatible
* Micropocessor based with OSD (On Screen Display) control.
* On Screen Control : Auto Adjustment, Contrast, Brightness,
H/V Position, H-Size, Phase, Color Control, OSD Position, Language,
Reset.
* Built-in color active matrix TFT (Thin Film Transistor) Liquid Crystal
Display (LCD) that uses amorphous silicon TFTs as a switching device.
* Multi-scanning at horizontal frequencies of 31kHz to 80kHz and vertical
frequencies of 60Hz to 75Hz.
* Compatible with standard IBM VGA, extended VGA, super VGA,
IBM XGA modes, super XGA, as well as VESA resolution standards
* Resolution : up to 1280 x 1024
* Dot pitch : 0.264mm(H) x 0.264mm(W)
* Universal power supply : AC 90 - 264V allowed
* Power consumption Normal :
Power Saving : < 3 Watt
Off :
* Outside dimension : 459mm(W) x 467mm(H) x 165mm(D)
* Weight (net) : 7.5kg
TM
< 40 Watt
< 3 Watt
3
