R 9.5e
8
PARTS LIST / TEILELISTE
No. Description
R9.5E-001
M6 x 10mm Bolt
R9.5E-002
Flywheel Shock Absorber
R9.5E-003
17 x 22 x T0.5 Plastic Washer
R9.5E-004
6003 Bearing
R9.5E-005
Flywheel Pulley
R9.5E-006
20 x 32 x T1.0 Plastic Washer
R9.5E-007
6004ZZ Bearing
R9.5E-008
M5 x 12 Bolt
R9.5E-009
Flywheel
R9.5E-010
Bearing bracket for 6003
R9.5E-011 CAP M8 x 15 Bolt
R9.5E-012 Aluminium Disk
R9.5E-013 M3 x 8 Bolt
R9.5E-014 Spring Washer 8 x 14 x 2
R9.5E-015 Electric magnet braket
R9.5E-016 M4 x 12 Flat head Bolt
R9.5E-017 M6 x 12 Bolt
R9.5E-018 Bearing bracket for 6004
R9.5E-019 M4 x 12 Bolt
R9.5E-020
Control Board
R9.5E-021
M6 x 100mm Bolt
R9.5E-022 Power set stable piece
R9.5E-023 Sensor stable piece
R9.5E-024 Sensor
R9.5E-025 Electric Magnet
R9.5E-026 Power set cover
R9.5E-027
M8 x 10mm Bolt
R9.5E-028
Stabilizer Tube Cap
R9.5E-029
Crank Cap
R9.5E-030
3/8" Nut
R9.5E-031
Crank - Left
R9.5E-032
M6 x 12mm Bolt
R9.5E-033
Crank Shaft
R9.5E-034
Drive Belt
R9.5E-035
Crank Disk
R9.5E-036
20 x 30 x T2.0 Washer
R9.5E-037
3/4" Nut
R9.5E-038
Crank – Right
R9.5E-039
Seat Post
R9.5E-040
Rear Vent Cover – Left
R9.5E-041
Rear Vent Cover - Right
R9.5E-042
Computer
R9.5E-043
Console Upright Tube
R9.5E-044
M6 x 15mm Bolt
Beschreibung
M6 x 10mm Bolzen
Schwungrad Stoßdämpfer
17 x 22 x T0.5 Plastikscheibe
6003 Kugellager
Schwungradrolle
20 x 32 x T 1.0 Plastikscheibe
6004ZZ Kugellager
M5x12 Bolzen
Schwungrad
Kugellagerklammer
M8 x15 Kopfschraube
Aluminium Disk
M3x8 Bolzen
Federscheibe 8x14x2
Klammer Elektromagnet
M4 x 12 Flachkopfschraube
M6x12 Bolzen
Kugellagerklammer
4 x 12 mm Schrauben
Systemplatine
M6 x 100mm Bolzen
Stabilisierungsstück Stromeinheit
Stabilisierungsstück Sensor
Sensor
Elektromagnet
Abdeckung Stromset
M8x10 mm Bolzen
Bodenrohrfußkappe
Kurbelkappe
3/8" Mutter
Kurbel links
M6x12mm Bolzen
Kurbelwelle
Antriebsriemen
Kurbelarm
20 x 30 x T2.0 Scheibe
3/4" Mutter
Kurbel rechts
Sattelrohr
Hintere Lüftungsabdeckung links
Hintere Lüftungsabdeckung rechts
Computer
Frontstütze Konsole
M6 x 15mm Bolzen
Qty. /
Menge
2
2
3
1
1
4
3
2
1
1
2
1
4
14
1
2
6
1
31
1
1
1
1
1
1
1
10
4
2
2
1
4
1
1
1
1
2
1
1
1
1
1
1
2
