Daikin J serie Installationshandbuch Seite 5

Outdoor Unit
L
O
Dimension
A
Model
RYN50LV1B 855
RYN60LV1B 855
Dimension
P
Model
RYN50LV1B 23
RYN60LV1B 23
K L
A
D
B C D E F
628 328 520 179 46
730 328 520 179 46
Q R S
362 73 75
362 73 75
1-3
All dimensions are in mm
G H I J K
93 149 101 113 603
93 149 101 113 603
C
G H
I J
L M N O
126 164 15 34
126 164 15 34
