S/N Item
1 Main lift slave platform exterior scissor arm weldment
2 Slave connecting rod weldment of main and sub lifts
3 Lower sliding block
4 Vertical-movement hinged shafts of main lift
5 Slave cylinder of main lift
6 Hinged shaft of piston rod
7 Safety gear weldment of main and sub lifts
8 Upper cover of safety jaw of sub lift and main lifts
9 Lower hinged shaft of slave cylinder
10 Center hinged shafts of main lift
11 Adjusting shim
12 Upper sliding block
13 Circlip for shaft
14 Type-1 non-metal insert hexagon lock nut
15 Circlip for shaft
16 Oilless bearing
17 Oilless bearing
18 Oilless bearing
19 Oilless bearing
20 CDQ2B thin cylinder
21 Pneumatic exhaust muffler joint
22 Cylinder straight joint
23 Hexagon socket screw with round head
24 Wire fixing clip
25 Cross recessed pan head screw
26 Push-in type grease nozzle
27 Short horizontal adjusting shim
28 Long horizontal adjusting shim
29 Lower wear washer
30 Expansion bolt
31 Hexagon nut
32 Hexagon bolt (full thread)
33 Hexagon bolt (full thread)
34 Plain washer
35 Standard spring washer
36 Hexagon socket screw with round head
37 Monolithic base frame weldment
AE5301/AE5301-3
中文
EN DE RU KO
Specification
2300x135x488
2300x450x135
100x60x61
40x30x77
36x219x33.2
610x144x202
620x110x200
31.5x34x215
24x30x462
31x42x5
100x46x61
30
M24
36
SF1-3025(2)
SF1-3055(2)
SF1-3040(2)
SF1-3055(3)
32x25
10
10
M5x55
WL-1-8
M5x10
8
300x50x3
900x50x3
900x80x1.2
M16x140
M16
M16x50
M16x80
8
8
M8x12
2530x598x80
