L4
Control channel 3 – Spots 1-4 and 5-8 occupy 6 channels. Eight spots occupy 12
channels.
L8
Control channel 4 – Each spot occupies the same 6 channels as every other. Eight spots
occupy 6 channels.
1~6 1~6

Dimmer Control Channels

Linear colour change following the movement of the slider.
Channel: Characteristic
1 Rainbow effect
2 Red 0 – 100%
3 Green 0 – 100%
4 Blue 0 – 100%
5 Strobe effect 80 – 1200 flashes/Min.
6 Sound control ON/OFF

CLEANING AND MAINTENANCE

The operator has to make sure that safety-relating and machine-technical installations are inspected by an
expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
The following points have to be considered during the inspection:
1) All screws used for installing the devices or parts of the device have to be tighly connected and must not
be corroded.
2) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension,
trussing).
3) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or
sediments. Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
1~6
1~6 1~6
18/35
7~12
1~6 1~6 1~6
