Wash by hand in cold water
Do not bleach
Do not tumble dry
Do not iron
Do not dry clean
• Check that the fabric and stitching are in good condition each time
you wash it.
• Prolonged exposure to direct sunlight can cause the fabric to fade.
To prevent friction from compromising the correct functioning of
the product, make sure that dust and dirt is removed from all mov-
ing parts.
CARRY BAG: 100% polypropylene
Components
Structure:
A1 – Base
A2 – Feet
A3 – Tubular seat elements
A4 – Backrest
A5 – Open/close buttons
A6 – Open/close junctions
A7 – Recline levers
A8 – Fitting for fabric
Padding:
B1 – Seat
B2 – Safety harness
B3 – Click buttons
B4 – Rigid trim for insertion of fabric
C – Carry bag
OPENING THE RECLINED CRADLE
The reclined cradle comes already assembled. To use it, the follow-
ing operations must be performed:
- Remove the reclined cradle from carry bag C (Fig.1); during the
opening phase pay attention to the moving parts.
- Take the tubular elements of the seat (A3) and pull outwards (Fig.
2).
- Open fully by pulling the junctions (A6) until they click, checking
that they are firmly in place (Fig. 3).
At this point you can choose the setting you prefer.
- To adjust the angle of the backrest take the two recline levers (A7)
at the same time and pull them upwards (Fig. 4); you can choose
from one of the three possible positions (Fig. 5-6-7). To complete
the operation, release the two levers (A7). This operation may also
be carried out with the child sitting in the reclined cradle. In this
case it can be more difficult.
WARNING: Always guide the backrest (A4) with your fingers when
adjusting the recline angle.
WARNING: Always check that the backrest is properly locked be-
fore use.
FIXED OR ROCKING MODE
The reclined cradle can be used in fixed or rocking mode:
- Fixed mode: turn the two feet (A2) towards the back of the reclined
cradle until the bottom of each foot touches the ground (Fig. 8).
- Rocking mode: turn the feet (A2) in opposite directions, so that the
feet are not touching the ground.
USING THE SAFETY HARNESS
- The safety harness is pre-fitted and ready for use the first time you
use the reclined cradle (Fig. 9).
- To release it, press the toothed ends of the clasp and remove the
two clasps (Fig. 10). The reclined cradle is ready for the child.
WARNING: When using, always fasten the belt by passing it
through the crotch strap and check it is tight enough and in the
right position.
It is possible to alter the tightness of the belt by adjusting it and
passing the strap around the back of the backrest.
- Hold one end of the clasp in place and simultaneously pull the
belt and slide it through the relative ring to adjust the tension of
the safety harness.
CLOSING THE RECLINED CRADLE
- The reclined cradle can be closed for transportation.
- During the closing phase pay attention to the moving parts.
WARNING: The reclined cradle must never be closed with the child
sitting in it. Remove the child from the reclined cradle before clos-
ing the frame!
To close the reclined cradle:
- Completely recline the backrest (A4) according to the indications
in the paragraph "ADJUSTING THE BACKREST" (Fig. 4).
- Press the 2 closing buttons (A5) and push the junctions (A6) to-
wards the centre of the structure (Fig. 11).
- To further compact the structure, push the tubular elements of the
seat (A3) towards each other until the reclined cradle is completely
closed (Fig. 12).
To reopen the reclined cradle follow the operations indicated in the
paragraph "OPENING THE RECLINED CRADLE".
HOW TO REMOVE THE FABRIC COVER
It is possible to remove the reclined cradle padding (B) in order to
wash it.
- Remove the safety harness (B2) from the rings on the padding (Fig.
13).
- Partially close the structure (A) so it is easier to remove the reclined
cradle cover.
- Turn over the reclined cradle (B3), undo the 4 buttons on the bot-
tom of the seat and the 4 buttons on the top of the backrest (Fig.
14-14A).
- Remove the padding by sliding the rigid trims (B4) upwards along
the rail (A8) until it is completely removed from the structure, mak-
ing sure not to damage it (Fig. 15-16-17-18).
- To put the cover back on the reclined cradle, carry out the same
process in reverse making sure, as with the previous operation,
that the rigid trims (B4) are inserted in the special slots at the top of
the rails (A8) (Fig. 19-20-21).
- Do up all the click buttons previously undone and reposition the
safety harness previously removed, passing it through the rings
(Fig. 22-22A).
WARRANTY
The product is guaranteed against any conformity defect in normal
conditions of use as provided for by the instructions for use. The
warranty shall not therefore apply in the case of damages caused
by improper use, wear or accidental events. For the duration of war-
ranty on conformity defects please refer to the specific provisions of
national laws applicable in the country of purchase, where provided
