Preparation For Work - Graphite 59G093 Betriebsanleitung

6. Internal flange
7. Switch lock button
8. Carbon brush cover
* There can be differences between the drawing and actual product.
DESCRIPTION OF USED GRAPHIC SIGNS
NOTE
WARNING
FITTING/SETTING
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Grinding wheel guard
2. Socket spanner
3. Additional handle
ATTACHING THE ADDITIONAL HANDLE
The additional handle (3) is installed in one of the holes in the grinder head. It is recommended to use the
grinder with the additional handle. When holding the grinder with both hands (also using the additional
handle), there is less risk of touching the grinder wheel or brush with your hand, as well as of injuries during
recoil.
INSTALLING AND ADJUSTING THE GRINDING WHEEL GUARD
The wheel guard protects the operator against flying broken pieces and accidental contact with a
working tool or sparks. The guard should always be fitted. Special attention should be paid so that
its covering part faces the operator.
• Install the grinding wheel guard (4) so the protrusion on its clip matches the notch on the grinder gear
casing.
• The wheel guard can be set in any position.
• Secure the mounting bolt.
The removal and adjustment of the wheel guard are performed in a reverse order to its installation.
REPLACEMENT OF WORKING TOOLS
When working tools are replaced, wear working gloves at all times.
The spindle lock button (1) is only designed to lock the grinder spindle, when a working tool is
installed or removed. Do not use it as a braking button, when the wheel rotates. Otherwise, the
grinder may become damaged or the user may be injured.
INSTALLING THE WHEELS
When grinding or cut-off wheels with the thickness below 3 mm are installed, the outer flange nut (5)
should be tightened with the flat surface from the wheel side (fig. B).
• Press the spindle lock button (1).
• Insert the special key (included) into two holes of the outer flange (5) (fig. A).
• Rotate the key to loosen and remove the outer flange (5).
• Place the wheel so it is pressed against the surface of the inner flange (6).
• Tighten the outer flange (5) and slightly tighten it with the special key.
- 1 pce
- 1 pce
- 1 pce

PREPARATION FOR WORK

21
