Außengerät:
56
55
No. Part Name
51 Rear wall
52 Cover for screwing connection
53 Feed-through for connecting line 60
54 Device base
55 Fan motor (condenser)
56 Fan motor attachment
57 Fan casing
24
57
53
51
No. Part Name
58 Sheathing for fastening clip
59 Condenser fan
Coupling set
61 Fastening clip for coupling
62 Service connection
63 Condenser
64 Front wall
58
60
61
62
54
52
Lokales Klimagerät PAC 4600
59
63
Spare parts (without figure)
Remote control
Fastening set for external unit
(compl.)
Wall holder
64
