1.2 Specifications
Platform
CPU
Chipset
Memory
Expansion Slot
Graphics
Audio
6
- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
- All Solid Capacitor design (100% Japan-made high-quality
Conductive Polymer Capacitors)
- Supports 2nd Generation Intel
LGA1155 Package
®
- Supports Intel Turbo Boost 2.0 Technology
- Supports K-Series unlocked CPU
- Supports Hyper-Threading Technology (see CAUTION 1)
®
- Intel Z68
- Dual Channel DDR3 Memory Technology (see CAUTION 2)
- 2 x DDR3 DIMM slots
- Supports DDR3 2133(OC)/1866(OC)/1600/1333/1066
non-ECC, un-buffered memory
- Max. capacity of system memory: 16GB (see CAUTION 3)
®
- Supports Intel Extreme Memory Profi le (XMP)
- 1 x PCI Express 2.0 x16 slot (blue @ x16 mode)
®
- Supports Intel HD Graphics Built-in Visuals: Intel
® TM
Sync Video, Intel InTru
®
Technology, Intel HD Graphics 2000/3000, Intel
Vector Extensions (AVX)
- Pixel Shader 4.1, DirectX 11 with Intel
®
DirectX 10.1 with Intel Sandy Bridge CPU
- Max. shared memory 1759MB (see CAUTION 4)
- Three VGA Output options: D-Sub, DVI-D and HDMI
(see CAUTION 5)
- Supports HDMI 1.4a Technology with max. resolution up to
1920x1200 @ 60Hz
- Supports DVI with max. resolution up to 1920x1200 @ 60Hz
- Supports D-Sub with max. resolution up to 2048x1536 @
75Hz
- Supports Auto Lip Sync, xvYCC and HBR (High Bit Rate
Audio) with HDMI (Compliant HDMI monitor is required)
(see CAUTION 6)
- Supports HDCP function with DVI and HDMI ports
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
with DVI and HDMI ports
- 7.1 CH HD Audio with Content Protection
(Realtek ALC892 Audio Codec)
- Premium Blu-ray audio support
ASRock Z68M-ITX/HT Motherboard
® TM
Core i7 / i5 / i3 in
®
Quick
®
3D, Intel Clear Video HD
®
Advanced
®
Ivy Bridge CPU,
