FEATURES AND CONTROLS

To electrode under test
(3 terminal test)
Battery compartment
(and charger socket
cover DET5/4R)
Condition
Warning l.e.d.s
Condition
Warning
Alert
8
To electrode under test
(4 terminal test)
Figure 1. DET5/4 Features
To Potential test spike
3 ⁄ digit L.C.D.
1
2
Low Battery indicator point
Ω and kΩ range indicator points
4 terminal push button
3 terminal push button
To Current test spike
Low Battery and
Range indicator
