1 - FEATURES OVERVIEW

• Accuracy +/- 1% of reading from 20% to 100% of full scale for operating temperature from +10°C to 40°C.
• Accuracy +/-2% of reading from 10% to 20% of full scale for operating temperature from 10°C to 40°C.
• Built-in torque transducer.
• For all small hand tools and non impacting power tools.
• Selection of two operation modes: Track, Peak.
• Four units of torque measurements: lbf.in, cN.m, N.m, kgf.cm.
• Four low-pass filter selections: 3000, 1500, 1000 and 500 Hz.
• Battery powered with up to 10 hours of operation.
• RS-232 interface to download readings in "real time."
• Large screen and easy to use menus.
• Two methods of calibration are provided, a single point calibration (using a manual pot adjustment) and a multipoint
calibration using ALPHA Calibration, a PC based Windows software program.
• Includes four run down adapters and a selection of both American and Metric screws along with washers to allow a close
simulation of actual joints.
• Includes ALPHA Terminal, for updating processor code and controlling torque direction to be displayed,
ALPHA Calibration for multipoint calibrations, and Data Acquisition Add-In for Excel that allows for ease of collecting
and analyzing data.

2 - IMPORTANT PRECAUTIONS

The ALPHA Digital Torque Tester is solely designed for measuring and testing of torque controlled equipment such as wrenches,
power tools or hand screwdrivers. CP, Inc. strongly recommends that this analyzer not be modified and/or used for any
application other than for which it is designed.

3 - RUN DOWN ADAPTERS

The ALPHA Digital Torque Tester features a female 17mm 6pt Hex Socket. The unit includes a 1/4 Female Hex Square Drive
Adapter as well as four run down adapters that slide into the socket. The run down adapters are dual sided (one side for American
size screw and other side for Metric screw). It also includes a selection of both American and Metric screws as well as washers
to allow a close simulation of actual joints.
Hardware kit (# 6159360300) includes the following items:
Neoprene washer:
Splitlock washer:
screws size
Amer. Phillips (8-32x3/8)
Metric Phillips (M5x12)
(.200x.750x3/32 THK)
(.125x.281x1/16 THK)
(M5 SS) (#8 STD SS)
max. torque size
17.8 lbf.in (6-32x3/8)
17.8 lbf.in (M4x12)
(.174x380x3/32 THK)
(.095x.235x1/16 THK)
(#6 SS)
max. torque size
8.7 lbf.in (4-40x3/8)
8.7 lbf.in (M3x10)
6159932830-02
English
5 / 124
(.149x.380x3/32 THK)
(M3 SS)
max. torque size
4.7 lbf.in (2-56x5/16)
4.7 lbf.in (M2x8)
(#2 SS)
max. torque
2.2 lbf.in
2.2 lbf.in
