tabla de direcciones 6
Lugar de válvula 14 bobina
1 bobina 1 (X.0)
2 bobina 3 (X.2)
3 bobina 5 (X.4)
4 bobina 7 (X.6)
5 bobina 9 (X+1.0)
6 bobina 11 (X+1.2)
7 bobina 13 (X+1.4)
8 bobina 15 (X+1.6)
9 bobina 17 (X+2.0)
10 bobina 19 (X+2.2)
11 bobina 21 (X+2.4)
12 bobina 23 (X+2.6)
tabla de direcciones 7
Lugar de válvula 14 bobina
1 bobina 1 (X.0)
2 bobina 3 (X.2)
3 bobina 5 (X.4)
4 bobina 7 (X.6)
5 bobina 9 (X+1.0)
6 bobina 11 (X+1.2)
7 bobina 13 (X+1.4)
8 bobina 15 (X+1.6)
9 bobina 17 (X+2.0)
10 bobina 19 (X+2.2)
11 bobina 21 (X+2.4)
12 bobina 23 (X+2.6)
13 bobina 24 (X+2.7)
tabla de direcciones 8
Lugar de válvula 14 bobina
1 bobina 1 (X.0)
2 bobina 3 (X.2)
3 bobina 5 (X.4)
4 bobina 7 (X.6)
5 bobina 9 (X+1.0)
6 bobina 11 (X+1.2)
7 bobina 13 (X+1.4)
8 bobina 15 (X+1.6)
9 bobina 17 (X+2.0)
10 bobina 19 (X+2.2)
11 bobina 21 (X+2.4)
12 bobina 22 (X+2.5)
13 bobina 23 (X+2.6)
14 bobina 24 (X+2.7)
12 bobina
bobina 2 (X.1)
bobina 4 (X.3)
bobina 6 (X.5)
bobina 8 (X.7)
bobina 10 (X+1.1)
bobina 12 (X+1.3)
bobina 14 (X+1.5)
bobina 16 (X+1.7)
bobina 18 (X+2.1)
bobina 20 (X+2.3)
bobina 22 (X+2.5)
bobina 24 (X+2.7)
12 bobina
bobina 2 (X.1)
bobina 4 (X.3)
bobina 6 (X.5)
bobina 8 (X.7)
bobina 10 (X+1.1)
bobina 12 (X+1.3)
bobina 14 (X+1.5)
bobina 16 (X+1.7)
bobina 18 (X+2.1)
bobina 20 (X+2.3)
bobina 22 (X+2.5)
-
-
12 bobina
bobina 2 (X.1)
bobina 4 (X.3)
bobina 6 (X.5)
bobina 8 (X.7)
bobina 10 (X+1.1)
bobina 12 (X+1.3)
bobina 14 (X+1.5)
bobina 16 (X+1.7)
bobina 18 (X+2.1)
bobina 20 (X+2.3)
-
-
-
-
AVENTICS | AV03/05 con IO-Link | R412018145–BAL–001–AC
Address-Data 6
Position 14 coil
1 coil 1 (X.0)
2 coil 3 (X.2)
3 coil 5 (X.4)
4 coil 7 (X.6)
5 coil 9 (X+1.0)
6 coil 11 (X+1.2)
7 coil 13 (X+1.4)
8 coil 15 (X+1.6)
9 coil 17 (X+2.0)
10 coil 19 (X+2.2)
11 coil 21 (X+2.4)
12 coil 23 (X+2.6)
Address-Data 7
Position 14 coil
1 coil 1 (X.0)
2 coil 3 (X.2)
3 coil 5 (X.4)
4 coil 7 (X.6)
5 coil 9 (X+1.0)
6 coil 11 (X+1.2)
7 coil 13 (X+1.4)
8 coil 15 (X+1.6)
9 coil 17 (X+2.0)
10 coil 19 (X+2.2)
11 coil 21 (X+2.4)
12 coil 23 (X+2.6)
13 coil 24 (X+2.7)
Address-Data 8
Position 14 coil
1 coil 1 (X.0)
2 coil 3 (X.2)
3 coil 5 (X.4)
4 coil 7 (X.6)
5 coil 9 (X+1.0)
6 coil 11 (X+1.2)
7 coil 13 (X+1.4)
8 coil 15 (X+1.6)
9 coil 17 (X+2.0)
10 coil 19 (X+2.2)
11 coil 21 (X+2.4)
12 coil 22 (X+2.5)
13 coil 23 (X+2.6)
14 coil 24 (X+2.7)
