About This Documentation
Safety instructions are set out as follows:
Hazard type and source
Consequences of non-observance
Precautions
<List>
Safety sign: draws attention to the hazard
Signal word: identifies the degree of hazard
Hazard type and source: identifies the hazard type and source
Consequences: describes what occurs when the safety instructions are not complied with
Precautions: states how the hazard can be avoided
Table 2: Hazard classes according to ANSI Z 535.6-2006
Safety sign, signal word
DANGER
WARNING
CAUTION
NOTICE
1.3.2

Symbols

The following symbols indicate information that is not relevant for safety but that assists in
comprehending the documentation.
Table 3: Meaning of the symbols
Symbol Meaning
If this information is disregarded, the product cannot be used or operated optimally.
Individual, independent action
1. Numbered steps:
2.
3. The numbers indicate sequential steps.
1.3.3

Designations

The following designations are used in this documentation:
Table 4: Designations
Designation
IO-Link interface
IO-Link master
SIGNAL WORD
Meaning
Indicates a hazardous situation which, if not avoided, will certainly
result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
Indicates that damage may be inflicted on the product or the
environment.
Meaning
IO-Link module with integrated valve drivers
Point-to-point communication partner to the IO-Link interface
