Device Overview
3.1
B-WIT 100 Wideband Injection Transformer
Delivery includes:
Injection transformer
BNC to 4 mm banana adapter
EARTH TERMINAL to connect
device to safety ground
Figure 3-1:
INPUT connector
BNC plug to connect the B-WIT 100
injection transformer to the signal source
OMICRON Lab
B-WIT 100 connector description
ISOLATED OUTPUT connectors
4 mm safety banana jacks for connecting the
injection transformer to the injection resistor
Device Overview
7
