5
Technical data
5.1
B-WIT 100 Wideband Injection Transformer
Table 5-1
Characteristic
Usable frequency range
Insertion loss
3 dB frequency range
Pri-Sec Isolation voltage
Pri-Sec capacitance
Max. volt-second
DC saturation current
Table 5-2
Characteristic
Absolute max current
Maximum AC voltage
Table 5-3
Characteristic
Operating temperature
Relative humidity
Maximum altitude
Table 5-4
Characteristic
Dimensions (with connectors)
Weight
S21 measurement with 50 Ω termination resistor.
1
S21 measurement with -10 dBm and 10 Ω secondary resistance (0 dB is normalized to 10 Ω termination).
2
OMICRON Lab
Specifications
1
2
Absolute maximum ratings (device will be destroyed)
Environmental conditions
Mechanical data
Rating
1 Hz – 10 MHz
< 0.5 dB @ 10 kHz
7 Hz – 5 MHz (typ.)
600 V CAT II
120 pF @ 1kHz (typ.)
3.5e-3 Vs (typ.)
15 mA (typ.)
Rating
1 A (fuse)
10 V
RMS
Rating
-20 °C ... +60 °C / -4 °F ... +140 °F
5 % ... 80 %
2,000 m / 6,561 ft
Rating
129 mm x 64 mm x 32.5 mm
5.1 inch x 2.52 inch x 1.28 inch
0.25 kg / 0.6 lbs
Technical data
11
