_ USING THE RAIN COVER

The rain cover can be stored in the baggage net.
Unfold the rain cover completely before use.
Pull it over the CONCORD QUIX from the top
down. Use the velcro straps to affix the rain
cover on the tube structure of the CONCORD
QUIX.
Leave the rain cover to dry out completely
before refolding and storing!

_ MAINTENANCE

Do not expose the cover to sunlight for long periods.
Wash the plastic parts with warm water and soap and carefully dry all the
components after.
Regularly check the brakes, harnesses and fastening elements that may
suffer wear and tear through use.
The cover can be removed for washing.
The individual elements of the CONCORD QUIX cover are interconnected
and attached to the tube frame via snap fasteners and velcro straps.
Open all fastenings before attempting to remove the cover. Pull the cover off
the seat area first, and then from the backrest.
When reattaching the cover, simply reverse the process. Thread the
harnesses through the relevant openings of the cover. Make sure that all
fasteners and connections are positioned correctly and are closed securely.
• The colour of the cover may run when
wet or in the wash.
• Do not use solvents on the cover!
