_ COLLAPSING THE CONCORD QUIX

CAUTION!
• Never collapse the CONCORD QUIX with your child in it.
Remove all items from the baggage net (13) and the seat before collapsing
the CONCORD QUIX.
Bring the backrest into its most upright position
(see SETTING THE SEAT TILT ANGLE),
Collapse the CONCORD QUIX
completely until you hear the transport
lock (11) locking into place.
manual_QUIX_130315-WEST-final.indd 21
fold the front part of the
sun visor inward, and tilt
the entire sunroof back
completely.
Move the upper and
lower TWINLOCK
control buttons (12)
up simultaneously and
bring together the two
handlebars (01) of
the CONCORD QUIX
forward and downward.
