_ USING THE PARKING BRAKE

Push the control button (09) on the right of the
handlebar (01) downward to activate the parking
brake.
Press the release button and move the operating
lever (09) on the right handle bar (01) upward to
release the parking brake.

_ LOCKING THE FRONT WHEELS

Turn the front wheels until they face
backwards and turn the control knob (08)
a quarter turn until it clicks into place if
you wish to lock the front wheels of the
CONCORD QUIX for straight forward
movement.
Turn the control knob (08) another
quarter turn to release the front wheel
lock.
