_ USING THE HARNESS SYSTEM

Shoulder harness
Lap harness
Central harness
Open the harness lock and place the harnesses to the sides and downward.
Place your child onto the seat as far back as possible.
Guide the central harness with the harness
lock up between the legs of the child. Click the
harness lock adapters of the shoulder and lap
harnesses into their respective receptacles in
the harness lock.
Simply press the central button on the harness
lock to release the individual harness adapters.
