Par ts List-
Parts# Description
TD210033 LAYSHAFT SET
TD220005 BALL DIFF SET
TD230026 1/10 ELECTRIC BIG BORE SHOCK SET: 35mm STROKE
TD230025 1/10 ELECTRIC BIG BORE SHOCK SET: 29mm STROKE
TD310020 SPUR GEAR 87T (48DP)
TD310031 SLIPPER CLUTCH PAD (2pcs)
TD310033 SHIM 10x12x0.1mm (10pcs)
TD310113 DRIVESHAFT BUSHING (2.0mm)(DEX410R/2010 Spec) (2pcs)
TD310123 DRIVESHAFT PIN A-TYPE 2.0mm (10pcs)
TD310135 ROLL PIN 1.6x14mm (DEX410R/2010 Spec) (2 pcs)
TD310238 IDLER GEAR SET
TD310239 PIN 1.5x7mm (10pcs)
TD310240 SLIPPER CLUTCH SPRING
TD310243 LAYSHAFT SPACER (1pc)
TD310244 SLIPPER HUB SET (1pr)
TD310246 SLIPPER SHAFT
TD310247 IDLER GEAR PIN (2pcs)
TD310255 ALUMINIUM MOTOR PLATE
TD310256 GEAR COVER
TD310262 BALL DIFF MAIN GEAR
TD310263 BALL DIFF PLATES (2pcs)
TD310264 BALL DIFF OUTDRIVES (1pr)
TD310266 BALL DIFF SCREW, SPRING AND NUT
TD310257 GEARBOX SET
TD310277 DRIVE SHAFT 96mm (2pcs)
TD310278 REAR AXLE (2pcs)
TD320121 BUMPER & REAR TOP DECK SET
TD320123 FRONT TOP DECK
TD320124 STEERING AND SERVO HORN SET
TD320127 REAR CHASSIS BRACE SET
TD320128 BATTERY STRAP & ANTI-ROLL BAR MOUNT SET
TD320149 DIMEC CHASSIS DEST210
TD320155 BODY MOUNT SET
TD320157 ALUMINIUM STEERING PLATE
.68.
Standard Par ts Parts# Description
TD320161 DEST210 BODY MOUNT SET
TD320158 MOTOR GUARD
TD330011 SHOCK CARTRIDGE & PISTON SET (4pcs)
TD330027 SHOCK STOPPER: RUBBER (4pcs)
TD330030 SHOCK O-RING (8pcs)
TD330033 PIVOT BALL A-TYPE (4pcs)
TD330034 PIVOT BALL B-TYPE (4pcs)
TD330035 PIVOT BALL C-TYPE (4pcs)
TD330036 PIVOT BALL D-TYPE (4pcs)
TD330037 SUSPENSION ARM PIVOT-BALL (8PCS)
TD330042 SHOCK SHAFT : FRONT (44mm 2PCS)
TD330043 SHOCK SHAFT : REAR (52mm 2pcs)
TD330151 BIG BORE SHOCK SPRINGS:65mm LIGHT BLUE (32gf/mm) (2pcs)
TD330157 BIG BORE SHOCK PISTON SET (4 SHOCKS)
TD330158 TURNBUCKLE M3x63mm (2pcs)
TD330160 BIG BORE SHOCK CAP O-RING (8pcs)
TD330155 BIG BORE SHOCK BODY: 35mm STROKE
TD330170 BIG BORE SHOCK BODY: 29mm STROKE (1pc)
TD330181 BIG BORE SHOCK CAP (4pcs)
TD330286 BIG BORE SHOCK SPRINGS:45mm NIGHT BLUE(108gf/mm)(2pcs)
TD330293 HD BALL END SET (Black)
TD330312 PLASTIC SHOCK COLLARS,14mm HEXES & SHOCK STAND OFF SET
TD330339 STEERING KNUCKLE & HUB SET
TD330340 HUB & KNUCKLE INSERT SET
TD330341 FRONT BULKHEAD & RF SUSPENSION MOUNT SET
TD330346 SHOCK ROD END PIVOT BALL (LONG)
TD330347 PIVOT BALL C-TYPE 10mm (4pcs)
TD330348 ALUMINIUM FRONT HINGE PIN BRACE
TD330350 HINGE PIN: REAR SUSPENSION INNER (41mm 2pcs)
TD330351 HINGE PIN: REAR SUSPENSION OUTER (37mm 2pcs)
TD330352 HINGE PIN: FRONT SUSPENSION INNER (35mm 2pcs)
TD330353 HINGE PIN: FRONT SUSPENSION OUTER (25mm 2pcs)
TD330363 PLASTIC SPACER SET
TD330380 SUSPENSION ARMS FRONT: 1 pair LEFT & RIGHT
TD330381 SUSPENSION ARMS REAR: 1 pair LEFT & RIGHT
TD330382 STEERING KNUCKLE SET
