Autoadapt Turny Low Vehicle Installationsanleitung Seite 31

3
4
5
6
7
Program movement path, swivel out
Switch between screen 8 and 9 to programme this path.
Lengthwise/swivel
8
Stepless Swivel
Out
Forwards
Backwards
9
10
Confirm the rear starting point.
Press 4 for Backwards until the screen 4 comes up.
Correct exit position.
Use 2 and 4, Forwards and Backwards, to run to the desired front end position.
(When screen 5 comes up it is possible to save the end position)
Press 3 to Save and continue programming.
(Screen 6 comes up)
Use 2 and 4, "Forwards" and "Backwards", to run to the desired rear end position.
(When screen 7 comes up it is possible to save the end position)
Tips!
The rear end position for comfort is the starting point for Swivel Out below. Mark
this starting position with a piece of tape. This marking can be useful in the event of
any editing of the Swivel Out path.
Press 3 to Save and continue programming.
The figure in the left corner shows how many degrees the seat is swivelled out.
Press 1 to select in the main menu at the top.
Press 2 to activate selected direction (displayed as a large symbol to the right of the
screen).
Press 3 for "Sequentially Swivel Out" (+1° at a time).
Press 4 to select direction Gradually Swivel Out, Forwards or Backwards.
"Gradually swivel out" is a combined swivel and forward movement. We recom-
mend first using this swivel first to achieve a gentle, smooth movement path.
Extend
Press 1 or 3 to select the main menu at the top.
Press 2 for In.
Press 4 for Out.
Exit
Press 1 to select in the main menu at the top.
Press 3 to save and exit from the programming mode. Turny Low Vehicle is now
back in normal operating mode.
Getting seated Turny Low Vehicle
(Screen 8 comes up)
