Autoadapt Turny Low Vehicle Installationsanleitung Seite 27

A Energy bracket
C 7/16 UNF x 22
D 7/16 UNF
E 12.5x26x2
Plug connections
1
E.g.
OEM seat belt attach-
ment with belt tensioner.
x 2 B
x 4
x 4
x 2 (if necessary)
x 12
2
1
Free the cable located under the cover
plate in the front centre part of the swivel.
Pull the cable through the square hole and
attach it to the energy bracket.
Energy bracket
3
4
2
Cabling from
Turny Low
Vehicle.
E.g.
OEM cabling under seat.
Getting seated Turny Low Vehicle
x 1
E.g.
OEM belt buckle with
belt tensioner and
switch.
4
3
27
EN
