10. Exit the emergency operation menu
Once installation is finished, put Turny Low Vehicle back into normal operating mode.
To return to normal operating mode, the criteria in item 10.1 must be met.
10.1
Swivel the seat in
Select the desired movement. Both directions for the movement selected must light
up before swivelling in may begin. For lengthwise operation and extension, the seats
may need to be moved forward a little to achieve this. Therefore, switch between
movements and directions to manoeuvre the seat in.
Select movement
Activate direction
Lengthwise and extension – move the seat backwards until the highlighted symbols
below grey out. The seat will stop automatically and emit an audible click. If necessary,
it is possible to override the system in this position and force the seat further back.
Hold the button down for 4 seconds. A countdown will begin in the display and at
the end the seat will continue backwards. The seat will stop automatically when it
reaches the end position; a click will be heard and the symbol will go out completely.
Swivel – swivel the seat in until the highlighted symbol below is extinguished. The
siege will stop automatically when it reaches its end position and emit an audible click.
Grey or off
10.2
Exit the emergency operation menu
When the lengthwise and extend symbols above are greyed out or off and the
swivel symbol is extinguished, the exit symbol will light up and allow exit from the
emergency operation menu.
1
2
Lengthwise Swivel
Both directions must light up first.
Off
Exit
Press 1 or 3 and select Exit.
Press 2 to confirm Exit. Turny Low Vehicle is now back in normal operating mode.
If this screen is displayed, the criteria for exiting the system have not been
achieved.
Go back and do 10.1 again.
Press 1 or 3 to select the main menu at the top.
Extend
Grey or off
