No. Description
1 CPU Fan Connector (CPU_FAN1)
2 2 x 204-pin DDR3 SO-DIMM Slots (DDR3_A1, DDR3_B1)
3 ATX Power Connector (ATXPWR1)
4 USB 3.0 Header (USB3_1_2)
5 USB 2.0 Header (USB2_3)
6 USB 2.0 Header (USB4_5)
7 Chassis Fan Connector (CHA_FAN1)
8 SATA3 Connector (SATA3_1)
9 System Panel Header (PANEL1)
10 SATA3 Connector (SATA3_2)
11 Chassis Speaker Header (SPEAKER1)
12 TPM Header (TPMS1)
13 Chassis Intrusion Header (CI1)
14 COM Port Header (COM2)
15 Clear CMOS Jumper (CLRMOS1)
16 Front Panel Audio Header (HD_AUDIO1)
