HELICOPTER
Stabilizer
Tail rotor
Position light

REMOTE CONTROLLER

Up/Down throttle stick
1. Unscrew the cover and
remove it.
Note: Before recharging and after every fl ight, always wait 10 to 15 minutes for the battery to cool down. This is in order to avoid damage to the battery. The charging process is electronically monitored, but you
should still monitor the device while charging.
1. Turn off the helicopter and the controller.
2. Carefully insert the charging cable plug into the
socket on the helicopter (pic. 1). The plug should fi t
easily into the socket – DO NOT FORCE. If the plug
is not inserted correctly into the socket, the aircraft
may be damaged and there is also a risk of injury.
3. Turn the control switch on the radio controller to
"Charge" (pic. 2).
4. The charge status LED turns green and indicates
the charge progress (pic. 3).
5. The aircraft is fully charged when the green LED
is no longer illuminated.
6. After charging, switch the Power to "OFF" and
remove the charging cable from the aircraft.
6
RC_Anleitung_Micro_Helicopter_Demonstrator_03.indd 6 RC_Anleitung_Micro_Helicopter_Demonstrator_03.indd 6
Helicopter and Controller
Landing gear
Infrared transmitter
Start control LED
Power LED
Control switch
2. Remove the battery holder. 3. Insert four 1.5 V AA batteries
Charging the Helicopter
The helicopter can fl y for about 6 minutes after
approximately 30 minutes of charging.
Counter-rotating
rotor blades
Spotlight

Insert Batteries

4. Replace the battery holder in
according to the polarity in the the compartment.
battery compartment.
Pic. 1
Spotlight
ON/OFF switch
Trim left/right buttons
Charge control LED
Fly backwards/ forwards
Fly left/right
Charge cable compartment
5. Close the battery compartment
and screw the cover back
in place.
Pic. 2
Pic. 3
