4. Oven enrollment
For all the details related to the link between app and product, available
also online at the following link: http://go.candy-group.com/hoover-ov
Wifi icon is managed the following way:
• when WiFi is off the icon is off (Figure 8)
• after a reset the icons blinks 1 seconds on and 1 seconds off and the
oven starts a new enrollment. There is a time slot of 5 minutes to
complete the enrolment starting from when user presses ok button on
standard or easy enrollment. Elapsed this time the WiFi is switched off
wifi icon disappears.
• if the oven is connected to a router the icon is switched on and the
oven is only controlled by remote.
TFT shows following image:
• when the oven is in read only mode the icon blinks 1 seconds on and 3
seconds off.
Figure 8
NOTE: Press smartphone icon to go to READ ONLY MODE.
READ ONLY MODE
You can read oven status related to temperature, cooking duration and
program.
BLINKING
BEHAVIOUR
oven is enrolling please follow quick guide for details on procedure
1s on 1s off
oven is in read only mode
1s on 3s off
oven is enrolled but has lost connection with router. It is not
3s on 1s off possible to send remotee control command. Please check your
router connection
oven is not enrolled. You can only start a new enrollment.
always off
WIRELESS PARAMETERS
Specifications
Parameter
Wireless Standart
802.11 b/g/n
Frequency Range
2,412 GHz. – 2,484 GHz
802.11b. DSSS 1 Mbps=
+19.5 dBm
802.11b. CCK 11 Mbps=
Max Transmit Power +18.5 dBm
802.11g. OFDM 54 Mbps=
+18.5 dBm
802.11n. MCS7=
+14 dBm
802.11b =1024 bytes,
-80 dBm
802.11g =1024 bytes,
-70 dBm
Minimum Receiving
Sensivity
802.11n =1024 bytes,
-65 dBm
802.11n HT40 =1024 bytes,
-65 dBm
MEANING
Specifications
(Wi-Fi) (Bluetooth)
Bluetooth v4.2
2,412 GHz. – 2,484 GHz
Basic data rate:
RF Transmit Power (Typ):
+4 dBm
Enhanced data rate:
RF Transmit Power (Typ):
+2 dBm
BLE:
RF Transmit Power (Typ):
+7.5 dBm
Basic data rate:
Sensivity@ 0.1% BER:
-98 dBm
Enhanced data rate:
Sensivity@ 001% BER:
-98 dBm
BLE:
Sensivity@ 0.1% BER:
-98 dBm
Product information for networked equipment
Power consumption of the product in
networked standby if all wired network
ports are connected and all wireless
network ports are activated:
How to activate wireless network port:
How to deactivate wireless network
port:

4.1. Meat Probe

After meat probe is inserted the display shows a message informing
the user that only manual program are available. Press ok at the
following pop up message to show available cooking modes. (Figure 9)
Figure 9
● The user can now select oven temperature (max 200 degrees) and
meat probe temperature (max 90 degrees). (Figure 10)
● Cooking stops when meat probe temperature reaches the selected
one.
● After removing meat probe TFT shows home screen and all cooking
are now possible.
GRILL+FAN CONVECTION
Figure 10

5. Oven cleaning and maintenance

5.1 General notes on cleaning

The lifecycle of the appliance can be extended through regular
cleaning. Wait for the oven to cool before carrying out manual cleaning
operations.
WARNING: Never use abrasive detergents, steel wool or sharp
objects for cleaning, so as to not irreparably damage the enamelled
parts. Use only water, soap or bleach-based detergents (ammonia).
GLASS PARTS
It is advisable to clean the glass window with absorbent kitchen towel
after every use of the oven. To remove more obstinate stains, you can
use a detergent-soaked sponge, well wrung out, and then rinse with
water.
OVEN WINDOW SEAL
If dirty, the seal can be cleaned with a slightly damp sponge.
EN 11
2,0 W
Navigate to settings -> ONE-FI ->
press for 3 seconds the ONE-FI icon
Display shows 2 possible ways to
enroll the oven: standard and easy
Press the ok button on one of them.
WiFi module is switched on and
WiFi icon blinks 1s on 1s off.
Navigate to settings -> ONE-FI ->
press for 3seconds the ONE-FI icon
Display shows 2 possible ways to
enroll the oven: standard and easy
D o n o t p r e s s t h e o k b u t t o n .
WiFi module is switched off and
WiFi is not shown.
Note: WiFi data if present are
deleted.
MULTI-LEVEL GRILL
+FAN
CONVENTIONAL
