RML10.4, RML10.4S, RML10.4T
4.5 Installing condensation drain
I
NOTE
• Condensation can form inside the refrigerator due to frequent door
opening, incorrectly stored food or food that is stored when it is too
warm.
• Condensation must be drained with a constant slope.
Install the condensation drain as follows:
Variant 1
➤ Run the condensation hose from the refrigerator through an opening in the floor
which goes outside under the vehicle.
Variant 2
➤ Attach the condensation hose directly to the fitting intended for it on the ventila-
tion grill (fig. c 1, page 8).
4.6 Install the roof vent
No. in
fig. d, page 8
1
2
➤ Seal the installation frame to make the connection waterproof (fig. e, page 8).
➤ Insert the installation frame and screw it down tightly (fig. f, page 8). Use all the
fixing holes for this.
➤ Insert the hood and screw it down tightly (fig. g, page 8).
EN
Description
Hood
Installation frame
Installing the refrigerator
19
