Machine Overview - Evolution R165 Ccsl Originalbetriebsanleitung

1
2
3
4
5
6
7
1. CUT MATERIAL EJECTION PORT
2. THUMB LEVER
3. MULTI-MATERIAL TCT BLADE
4. LOWER BLADE GUARD
5. PARALLEL EDGE GUIDE
6. ERGONOMIC FRONT HANDLE
7. CARBON BRUSHES
8. 8MM HEX KEY (BLADE CHANGE)
9. DEPTH ADJUSTMENT LOCKING LEVER
10. DEPTH SCALE
11. REAR HANDLE
12. UPPER BLADE GUARD
www.evolutionpowertools.com
USA
16
15
14
13
12
11
8
13. PRECISION ENGINEERED SOLE PLATE
14. THUMB LEVER
15. PROTRACTOR SCALE
16. ARBOR LOCK BUTTON
17. DUST PORT CONNECTOR
18. 25/32" INNER BLADE FLANGE
19. 5/8" INNER BLADE FLANGE
12
17
18
19
