Model AW434C and AW434C–2 Impact Wrenches are designed for use in general
automotive repair, body shops, front end service and light truck and farm equipment
applications.
Mac Tools is not responsible for customer modification of tools for applications on which
Mac Tools was not consulted.
IMPORTANT SAFETY INFORMATION ENCLOSED.
READ THIS MANUAL BEFORE OPERATING TOOL.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PLACE THE INFORMATION
IN THIS MANUAL INTO THE HANDS OF THE OPERATOR.
FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.
PLACING TOOL IN SERVICE
Always operate, inspect and maintain this tool in
accordance with all regulations (local, state,
federal and country), that may apply to hand
held/hand operated pneumatic tools.
For safety, top performance, and maximum
durability of parts, operate this tool at 90 psig
(6.2 bar/620 kPa) maximum air pressure at the
inlet with 3/8" (10 mm) inside diameter air supply
hose.
Always turn off the air supply and disconnect the
air supply hose before installing, removing or
adjusting any accessory on this tool, or before
performing any maintenance on this tool.
Do not use damaged, frayed or deteriorated air
hoses and fittings.
Be sure all hoses and fittings are the correct size
and are tightly secured. See Dwg. TPD905–1 for a
typical piping arrangement.
Always use clean, dry air at 90 psig maximum air
pressure. Dust, corrosive fumes and/or excessive
moisture can ruin the motor of an air tool.
Do not lubricate tools with flammable or volatile
liquids such as kerosene, diesel or jet fuel.
Do not remove any labels. Replace any damaged
label.
USING THE TOOL
Always wear eye protection when operating or
performing maintenance on this tool.
Always wear hearing protection when operating
this tool.
The use of other than genuine Mac Tools replacement parts may result in safety hazards, decreased tool performance,
and increased maintenance, and may invalidate all warranties.
Repairs should be made only by authorized trained personnel. Consult your nearest Mac Tools Authorized Servicenter.
 Mac Tools, 2000
Printed in U.S.A.
INSTRUCTIONS FOR
MODELS AW434C AND AW434C–2
HEAVY–DUTY IMPACT WRENCHES
Mac Tools, Inc.
PO Box 32940
Columbus, OH 43232
04577045
Keep hands, loose clothing and long hair away
from rotating end of tool.
Note the position of the reversing lever before
operating the tool so as to be aware of the direction
of rotation when operating the throttle.
Anticipate and be alert for sudden changes in
motion during start up and operation of any power
tool.
Keep body stance balanced and firm. Do not
overreach when operating this tool. High reaction
torques can occur at or below the recommended
air pressure.
Tool shaft may continue to rotate briefly after
throttle is released.
Air powered tools can vibrate in use. Vibration,
repetitive motions or uncomfortable positions may
be harmful to your hands and arms. Stop using
any tool if discomfort, tingling feeling or pain
occurs. Seek medical advice before resuming use.
Use accessories recommended by Mac Tools.
Use only impact sockets and accessories. Do not
use hand (chrome) sockets or accessories.
Impact wrenches are not torque wrenches.
Connections requiring specific torque must be
checked with a torque meter after fitting with an
impact wrench.
This tool is not designed for working in explosive
atmospheres.
This tool is not insulated against electric shock.
Form 7449
GB
Edition 2
June, 2000

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für MAC TOOLS AW434C-Serie

  • Seite 9 Die Schlagschrauber der Baureihen AW434C und AW434C–2 werden eingesetzt in Kfz–Reparatur–, Karrosserie–Werkstätten, Motor/ Getriebe–Service, Kleinlaster und landwirtschaftliche Maschinen und Geräte. Mac Tools lehnt jede Haftung für Veränderungen an Werkzeugen ab, die ohne vorherige Rücksprache mit Mac Tools vorgenommen werden. ACHTUNG NACHFOLGEND WICHTIGE SICHERHEITSHINWEISE.
  • Seite 10: Anweisungen Auf Warnschildern

    ANWEISUNGEN AUF WARNSCHILDERN ACHTUNG DIE NICHTEINHALTUNG DIESER WARNHINWEISE KANN ZU VERLETZUNGEN FÜHREN. ACHTUNG ACHTUNG ACHTUNG Beim Betreiben oder Warten Beim Betreiben dieses Vor Wartungsarbeiten oder dieses Werkzeuges stets Werkzeuges stets dem Austausch von Zubehör Augenschutz tragen. Gehörschutz tragen. ist das Werkzeug von der Druckluftversorgung ab- zuschalten.
  • Seite 11: Technische Daten

    Inbetriebnahme des Werkzeugs und nach jeweils acht MIT ZWEIFACHEM Betriebsstunden die Ölkammerschraube lösen und die DURCHMESSER DES LUFTEINLASSES KOMPRESSOR Ölkammer mit Mac Tools-Öl füllen. Nach jeweils 48 Betriebsstunden oder je nach Erfahrung REGELMÄSSIG ungefähr 4 ccm des empfohlenen Fettes in den ABLASSEN Schmiernippel (2) einspritzen.
  • Seite 12: Konformitätserklärung

    KONFORMITÄTSERKLÄRUNG Mac Tools (Name des Herstellers) Columbus, OHIO 43232 USA (Adresse) erklären hiermit, gemäß unserer alleinigen Verantwortung, daß die Geräte: Hochleistungs–KFZ–Schlagschrauber der Baureihe AW434C und AW434C–2 auf die sich diese Erklärung bezieht, den Richtlinien: 98/37/EG unter Anlehnung an die folgenden Grundnormen...
