ASROCK J5005-ITX Schnellinstallationsanleitung Seite 5

I/O Panel
1 2
14 13
No. Description
1 PS/2 Mouse Port
2 D-Sub Port
3 LAN RJ-45 Port*
4 Central / Bass (Orange)
5 Rear Speaker (Black)
6 Line In (Light Blue)
7 Front Speaker (Lime)**
12 11
No. Description
8 Microphone (Pink)
9 Optical SPDIF Out Port
10 USB 2.0 Ports (USB_01)
11 USB 3.1 Gen1 Ports (USB3_01)
12 HDMI Port
13 DVI-D Port
14 PS/2 Keyboard Port
J5005-ITX
J4105-ITX
4 6
5 7
3
9 8
10
3
