3. SYSTEM OPERATING INSTRUCTIONS
3.1 Pre-op preparation
1. Choose the appropriate set-up per Section 2.2 for the intended procedure.
2. Verify the power cord is plugged into the unit and an appropriate electrical receptacle.
3. Verify the footswitch tubing is attached to the unit. Uncoil the footswitch tubing and place the
footswitch near the operator's station.
4. Turn on the power switch. Note: On is the "I" position. Off is the "O" position.
5. Rotate motor speed control knob slightly to verify that the motor speed varies.
6. Press the footswitch to ensure that the unit starts and stops using the footswitch.
7. Turn off the power switch until the smoke evacuator is required.
3.2 Operative Use
Warning:
suction control and the position of the inlet end of the suction tubing or wand to
prevent injury to the patient or inadvertent damage to surgical materials.
Warning:
may cause rapid reduction of the pneumoperitoneum in laparoscopic procedures.
1. Move the SurgiFresh® Turbo into position near the procedure area.
2. Attach tubing per the instructions in Section 2.2.
3. Turn on the power switch.
4. The footswitch may be pressed by personnel in the procedure area to start and stop the
suction as needed during the procedure. Place the footswitch in a convenient location.
5. Rotate the motor speed control knob clockwise to increase air flow (suction) and
counterclockwise to decrease air flow. Stop at desired setting.
6. Verify adequate air flow is set by inquiring with the surgeon. Adjust as necessary with the
motor speed control knob. Turning the knob completely clockwise places the unit in turbo
mode.
7. When the procedure is finished, turn off the power switch.
8. Collect the footswitch and electrical cord.
Follow cleanup instructions per Section 3.4.
3.3 Maximizing Use Suggestions
1. Air flow
a. The distance of the tubing from the plume source affects capture and removal of the
plume. The tubing end should be within several inches of the procedure site.
b. Larger tubing will permit a higher volume of flow for better plume removal. Do not
occlude tubing.
2. Noise
a. Lower speed equals lower noise.
b. Larger tubing equals lower noise. Do not occlude tubing.
c. Use the footswitch to turn the suction on and off as it is needed during the procedure.
3. Incidental Fluids
a. Replace filters immediately if contaminated by fluids.
b. The SurgiFresh® Turbo should not be used as a primary fluid suction system.
OPERATING INSTRUCTIONS
The smoke evacuator produces a strong vacuum. Properly adjust the
Some cannulas, valves, or other instruments combined with suction
