7. TECHNICAL SPECIFICATIONS SURGIFRESH TURBO 230V
All specifications are nominal and subject to change without notice.
Filters
Pre-filter:
ULPA filter:
Air Flow
Motor Speed
* Air flow is tested at 230 VAC in a controlled environment using a digital anemometer.
Maximum Static Suction
92 inches H20 (172mm Hg) suction pressure motor fan rating (sealed)
Safety
Circuit breakers: 5 amps / ea
Power cord: 10 feet, IEC to 2 prong continental European
Leakage Current (50 HZ): 300µA max.
Power
Input mains voltage (nominal): 230 VAC
Mains frequency (nominal): 50 Hz PN 906750
(refer to serial number tag on rear of unit)
Mains current: 3.25 amps maximum during normal operation
Physical Characteristics
Height: 25 1/4 inches (57.8 cm)
Depth: 10.5 inches (28 cm)
Width: 9 1/8 inches (23.2 cm)
Weight: 27.25 pounds (9.7 kg) without filters, hoses or box
8.

TRANSPORT AND STORAGE

Ambient temperature range –40°F to 158°F (-40°C to 70°C)
Relative Humidity: <75%, noncondensing
Use original packaging materials when shipping or transporting via carrier

SPECIFICATIONS

captures medium and large particles > 0.3 microns
0.1 micron particulate size at 99.9995% efficiency; activated high grade
carbon for gas and odor adsorption
1 1/3 in. X 6 ft.
Setting (3.4 cm)
0% 45 cfm
50% 50 cfm
100% 60 cfm
7/8 in. X 6 ft.
(2.2cm)
25 cfm
30 cfm
35 cfm
11
3/8 in. X 6 ft.
(1 cm)
5 cfm
6 cfm
7 cfm
