2. SYSTEM SET-UP
2.1 Installation
The SurgiFresh® Turbo with manual will arrive in a single carton. Inspect the carton and the
product for any scratches, dents or damage which may have occurred during
shipment. If any damage is noted, follow the instructions per the Warranty section.
Smoke evacuation disposables filters, tubing and accessories may be shipped separately. The
same shipping damage instructions apply to these items.
After removal from the carton, the SurgiFresh® Turbo is set up as follows:
Note:
1. Connect the footswitch tube to the side tubing port on the smoke evacuator. Place the
footswitch control in the footswitch mode. If the footswitch is not desired for use, override
the footswitch by placing the footswitch control in the normal mode.
2. Install an ULPA filter in the central core of the unit. Note the air flow direction arrow on the
ULPA filter. The arrow should be pointing downward. Be sure the are no obstructions and
the filter seats completely by pushing all the way down.
Note:
unit. The normal replacement is 90 days from the date of installation. Early replacement is
possible due to heavy usage as indicated by the ULPA filter test or odor.
3. Connect the power cord to the unit and an appropriate electrical receptacle.
4. Perform the ULPA filter test per the procedure in Section 4.2.
Note:
testing is satisfactorily completed, turn the motor speed knob to approximate ¼ speed to
ensure that the unit will not be activated at high speed.
5. Install a pre-filter to the top of the ULPA filter.
Caution:
proper suction flow.
6. Determine the type of procedure, select the appropriate tubing and accessories, and
prepare the unit for use as described in Section 3.1
2.2 Typical Setup Instructions
1. OPEN PROCEDURES -- EVACUATING DRY PLUME / SMOKE
a. Ensure an ULPA filter and applicable pre-filter are installed per section 2.1.
b. Connect an adapter if required and/or tubing appropriate for the procedure to the pre-filter.
OPERATING INSTRUCTIONS
Save carton and packing for future use.
Fill out the date sticker (included with filter) and apply it to the top of the
The ULPA filter test is performed with no pre-filter or tubing in place. After
Be sure both the ULPA filter and pre-filter are securely seated to ensure
5
