Refer to the table below for an overview of the control signals per channel.
Channel DMX-512 value Function
CH1
CH2
7.

Cleaning and maintenance


All screws should be tight and free of corrosion.

The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting
supports, do not change the location of the connections ...

Mechanically moving parts must not show any signs of wear and tear.

The electric power supply cables must not show any damage. Have a qualified technician maintain
the device.

Regularly remove dust from the housing and the air vents using a slightly damp cloth.

There are no user-serviceable parts inside. Refer to an authorized dealer for service and/or spare
parts.
8.

Technical Specifications

power supply .................................................................................... 240 V~, 50 Hz
power consumption ........................................................................................ 15 W
light source ............................................................... 1x high-power 10 W CREE LED
dimensions .............................................................................. 280 x 280 x 150 mm
weight ......................................................................................................... 2.6 kg
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulting from (incorrect) use of this device. For more info
concerning this product and the latest version of this manual, please visit our website
www.hqpower.eu. The information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved. No part
of this manual may be copied, reproduced, translated or reduced to any electronic medium or otherwise
without the prior written consent of the copyright holder.
V. 02 – 03/11/2017
000 ~ 255 dimmer: 0% ~ 100%
water effect enabled+ colour changing
000 ~ 063
water effect fixed + colour changing
064 ~ 127
water effect enabled + colour fixed
128 ~ 191
water effect fixed + colour fixed
192 ~ 255
VDPL110WL
6 ©Velleman nv
