GENERAL DESCRIPTION
1. Dough hooks and beaters release button
2. Switch and speed control (5 settings)
3. TURBO button - high speed
4. Body of the mixer
5. Beaters
6. Dough hooks
7. Blender
8. Housing
TECHNICAL DATA
- power: 200W
- supply voltage: 230V ~ 50Hz
- maximum time of continuous
operation: 5 minutes
- interval time before reuse:
10 minutes

APPLIANCE OPERATION

Before the first use wash the dough hooks (6), beaters (5) and blender (7).
(see chapter: CLEANING AND MAINTENANCE).
photo 2
CAUTION
Watch the continuous operation time of the appliance. The extended operation time and
the lack of breaks may lead to the irreversible damage to the engine and loss of warranty.
In the case of stopping the appliance while operation, before cleaning, unplug it and wait
till the attachments stop to whirl.
If the appliance slows down while operation it needs a break and, if possible, liquefying
ingredients.
INSTRUCTIONS FOR USE
1
8
ASSEMBLY
- make sure the appliance is unplugged, and the switch (2) is set in the
position "0"
- place the dough hooks (6) or beaters (5) in proper sockets on the
bottom part of the mixer (4), photo 2.
Attachments need to be assembled in pairs - two dough hooks (6) or
two beaters (5).
Assemble the attachments in the order shown in the photo 2. Insert the
flanged ending into the socket marked on the housing of the body (4)
with the symbol
- before the operation make sure that all the components were
assembled properly
- plug in the appliance
- the mixer starts its operation after a proper speed is selected with the
switch (2).
By changing its position 5 different speeds can be obtained.
TURBO button is used to achieve immediately the maximum speed
corresponding to the position "5" of the switch (2)
When whisking or mixing is finished, one should:
- slide the switch (2) to "0" position and unplug the mixer;
- pull the attachments from the sockets by pressing the button (1)
3
2
5
6
5
MIXER R100
4
7
photo 1
