General device description

2 General device description
e:cue SYMPL Nodes are a system of interfaces for e:cue SYMPHOLIGHT
only. They provide various connection types like DMX512, DALI, digital
inputs and outputs etc. SYMPL Nodes always operate in online mode, as a
device interface for SYMPHOLIGHT. All interactions are initiated and
controlled by SYMPHOLIGHT. Connections between servers, Cores and
Nodes are always made with e:net via Ethernet.
The e:cue SYMPL relay Node is a switching interface for use with e:cue's
lighting control solution SYMPHOLIGHT. It provides three relay interfaces in
single-pole double-throw configuration. The e:cue SYMPL relay Node can
be powered by an external power supply or via Power-over-Ethernet. It is
easily mounted on standard 35 mm DIN rails, or with a key hole in the
housing base on walls or on any stable vertical surface. The e:cue
SYMPL relay Node is a simple, reliable and easy to use interface solution
for e:cue lighting control solutions with SYMPHOLIGHT.
To operate SYMPL Nodes a SYMPHOLIGHT version 2.0 or
i
higher is mandatory. Earlier versions do not support the
SYMPL Nodes. SYMPL Nodes are not supported by the
e:cue Lighting Application Suite.
e:cue SYMPL relay Node is not hot-pluggable.
i
2.1

Delivery content

Delivery content for the e:cue SYMPL relay Node (AB444190035):
1. e:cue SYMPL relay Node
2. Safety instructions
3. Installation guide (English only)
