Installation

4 Installation
The installation of the SYMPL relay Node consists of mounting the device,
connections to loads, to e:net, and to power supply.
The sequence of cabling is not defined. Supply the SYMPL relay Node with
power after all cabling is completed; it starts booting.
Connect cables and data only when the device is powered
!
down.
Each cable should not exceed a length of 30 m.
!
4.1

Installation conditions

Installation position:
Horizontal spacing:
Minimum vertical rail grid spacing:
Recommended vertical rail grid spacing:
Installation location
4.2

Mounting process

The e:cue SYMPL Node is designed to mount onto a 35 mm DIN rail
(EN 60715) in a vertical position.
14
Terminals on top and bottom
No spacing necessary
115 mm (90 + 25 mm)
(excluding conduit)
160 mm (with 40 mm conduit)
Indoor
