General device description
2.3
User interface: LEDs
The SYMPL relay Node has six LEDs. The six LEDs show the basic states
of the SYMPL Node.
LEDs
Status
e:net
Test / Error
Status +
Test / Error
Status relay 1
to 3
2.4
Identify button: Identification & Reset & Testing
The Identify button has four functions: to send an Identify message (A), to
reset the Node (B), to test the installation (C), and to exit the error state (D).
10
On: If constantly on, the device is online. Server
application is in operation.
Blinking: If blinking in one second intervals, the device is
offline, no connection to a SYMPHOLIGHT server or
Core is available. If blinking more rapidly, the device is in
bootloader mode.
Off: no link available.
On: link established.
Blinking: e:net traffic.
Off: no error detected.
Short-short-long sequence: Test mode active.
On: If constantly lights in red, an error occurred. This
can be an internal error or malfunction of the device, or
an external error, e.g. a shortcut of interface
connections or alien power supply. Switch the device off
and on. If the error persists, check the wiring or contact
OSRAM Service.
The Status and Test / Error LED blink simultaneously to
identify the SYMPL Node (enabled "Identify Interface
Mode" in SYMPHOLIGHT).
Off: relay inactive (=open).
Orange: relay active (=closed).
