Connecting the thermostat to a wireless receiver (RCR114.1) or valve actuator (SSA911.01TH)
Overview of connected devices
A6V11562445_en--_a
1. Power up RCR114.1 (via wire) or SSA911.01TH (with battery).
2. On the thermostat Home screen, tap
Advanced settings screen displays.
3. Enter the administrator password when prompted.
4. Tap and then
5. Tap Pair new devices, then follow the on-screen instructions to
press the push button on RCR114.1or SSA911.01TH. Depending
on your set-up, establishing the connection may take some time.
Notes:
a. Set the DIP switch on RCR114.1 to configure the device as a
relay or repeater before connecting it to the thermostat.
b. Add a repeater (RCR114.1) if the connection fails due to low
signal strength (distance or blockades (walls, etc.)).
c. The thermostat can only connect to one heating system type
at a time – so it cannot simultaneously control a wireless relay
and a valve actuator.
d. The thermostat can control up to 6 wireless relays or up to 6
valve actuators.
1 Wireless repeater (RCR114.1 only)
2 Relay or actuator (RCR114.1 or
SSA911.01TH)
3 Signal strength of connected
device
4 Remove device
, then
.
5
6
7
8
and . The
Device not reachable or
communication failure
Low battery
(SSA911.01TH only)
Tap to view all devices
Add more devices
