Appendix A : Characteristic curves
Appendix B : Installation suggestions

Fixed installation

1a Coupling pedestal
1b Guide piece
1c Pipe clamp
2 Flange elbow
3 Guide pipe 5/4''
Portable installation
4 Backflow preventer
5 Wedge-type flat slide valve
6 Lowering chain with clevis
7 Supporting ring
9 Pressure pipe
