TANGO WALKING FRAME
TANGO is a foldable four-wheel walking frame for both indoor and
outdoor use with swivelling wheels at the front.
TANGO has been tested and approved for a user weight of
max 125 kg.
FOLDING
Folding: Apply the parking brake.Fold together the walker by pulling
the red handle upwards. Avoid using the walker as support during the
folding process.
Unfolding: unfold by pressing down the seat's frame.
Note! The seat must be properly in place when using the walking
frame. The seat is properly in place when you hear a click.

HEIGHT ADJUSTMENT

2
The handles are adjustable in height from 76 cm to 98 cm. When the
1
height is tested the height of the upper part of the handles should
3
match the height of your wrists (see picture).
Loosen the knob (1). Turn the handles inwards (2). Adjust the handles
(3) to required height and tighten the knob.
If the walking frame feels unstable after use check that all knobs are
properly tightened.
BRAKES: HOW TO USE
The brakes can be used in two different directions. If the brakes are
pulled upwards TANGO brakes for as long as you hold the brakes.
If the brakes are pressed downwards, the parking brake is activated.
To release the parking brake just pull the brake upwards again and the
brake is released.

ADJUSTING THE BRAKES

When adjusting the brakes, loosen the screw and move the adjusting
splint.
The distance between the adjusting splint and the tyre should be
approx. 7 mm.
