Only the service provider and/or a specialised technician are authorised to
performing servicing and repairs.
Fire safety
In the event of a fire, use carbon dioxide (CO
or powder extinguishers.
3 KEY TO MACHINE COMPONENTS (FIG.01)
1 Control panel
2 Pod loading tray
3 Brew unit
4 Steam wand
5 Cup rest grill (small cups)
6 Cup rest grill (large cups)
7 Used pod drawer and drip tray
8 Power cord
9 Cup warmer always on
10 ON/OFF switch
3.1 Description of control panel (Fig.02)
11 Large coffee When this button is pressed the machine will
button brew a large coffee (quantity programmed by the
service provider).
12 "LANGUAGE" It allows the user to display messages in the
button desired language
13 Espresso When this button is pressed the machine will brew
button an espresso coffee (quantity programmed by the
service provider).
14 Manual dispensing When this button is pressed the machine will di-
button spense a quantity of product manually controlled
by the user (the user must stop the machine by
pressing the STOP button).
15 Button When you press this button the machine will in-
1 - Steam stantly dispense steam
2 - Stop Pressing this button will stop flow when the machi-
ne is brewing coffee/other beverages or dispen-
sing steam
16 LCD Display It displays the machine status and any alarms as well
as guiding the user in the operation of the machine.
4

USING THE MACHINE

4.1

Switching on the machine

Warning! Only the service provider is authorised to make the
connection to the mains power supply!
Before switching on the machine, make sure the plug is properly inserted in
the electric socket.
To switch on the machine, move the ON/OFF switch on the back to "I" (Fig.03).
10:30 11 Feb 04
The display will show:
Warming up
Wait please...
At this time the machine is warming up.
When the machine reaches the right temperature for brewing the beverage,
the display will show:
10:30 11 Feb 04
Ready
Insert pod
• 20 •
Now the machine is ready to dispense the beverage.
til reaching the required amount. For further explanation see section 4.9.
) extinguishers. Do not use water
2
The machine has been designed to display messages in different languages.
To select the desired language, press the "LANGUAGE" button until the
language you prefer appears on the display.
The machine is designed to correctly dispense beverages in small cups and/or
larger-sized containers.
The cups and/or mugs must be correctly positioned beneath the brew unit.
When dispensing in small cups, use the upper grill (Fig.05).
When dispensing in larger cups, mugs and/or glasses, use the lower grill,
turning the upper grill counterclockwise by hand to move it out of the way
(Fig.06).
and made to prepare a single serving.
To insert a pod, it is necessary to open the loading tray.
To open the tray, pull it out all the way (Fig.07).
The display will show:
Take a single pod by hand and place it on the outermost part of the slide (Fig.08).
Gently push the pod into place inside the machine (Fig.09).
When the pod is correctly positioned, close the tray (Fig.10).
Note: if the machine is connected to a coin mechanism, in order to
brew coffee or other beverages the user must first insert coins un-
4.2 Selecting the display language (Fig.04)
Note: the display language can be changed at any time during
machine operation.
4.3

Using cups, mugs and glasses

Warning! Do not use containers that stick out from the edge of the
grills they are resting on.
Note: if the cups and/or mugs are not correctly positioned beneath
the brew unit, the beverage may spill out of its container.
4.4

Inserting pods

Warning! To prepare the desired drinks, use only LAVAZZA pods
supplied directly by the service provider. Each pod is designed
Do not use pods other than those supplied by the service provider,
coffee beans, preground and/or freeze-dried coffee.
Do not reuse the same pod to prepare two or more drinks.
10:30 11 Feb 04
Insert pod
Close pod tray
Warning! Do not attempt to force it out beyond the limit.
Warning! The pod must be positioned as shown in the picture.
Note: the pod must be fitted into place without using any further
tools; after being inserted, the pod may no longer be extracted.
