Stopping the Tractor and Engine
WARNING
Fuel and its vapors are extremely ammable and
explosive.
Fire or explosion can cause severe burns or
death.
• Do not choke the carburetor to stop the engine.
1. Return the ground speed control(s) to neutral.
2. Disengage the PTO and wait for all moving parts to stop.
3. Move the throttle control (or throttle/choke control) to
SLOW position and turn the ignition key to OFF. Re-
move the key.

Emptying the Catcher

1. Extend the grass catcher handle and rotate forward until
the grass catcher assembly is completely open at the
bottom (see Figure 9).
2. Empty the grass from the catcher.
3. Rotate the grass catcher assembly back to the closed
position before mowing.
en

Cutting Height Adjustment

The mower lift lever (A, Figure 10) is used to lower and raise
the deck to the desired cutting height. The cutting height is
adjustable between 2,5 cm (1,0") and 8,9 cm (3,5").
To lower the deck, pull back slightly on the mower lift lever,
push it to the left and slide it down. To raise the deck, pull
up on the mower lift lever and lock in notch to the right.

Attaching a Trailer

The maximum horizontal drawbar force allowed is 280
Newton. The maximum vertical drawbar force is 160
Newton. This equates to a 113 kg (250 lbs) trailer on a 10
degree hill. Secure the trailer with an appropriately sized
clevis pin (A, Figure 11) and clip (B).
23
