Appendix – Bus master configuration
Table 35 Address assignment on a valve system, byte 0 to byte 3
Valve position Solenoid LED
1 14
12
2 14
12
3 14
12
4 14
12
5 14
12
6 14
12
7 14
12
8 14
12
9 14
12
10 14
12
11 14
12
12 14
12
13 14
12
14 14
12
15 14
12
16 14
12
Single solenoid valves only use solenoid 14.
Byte Address
0 A0.0
A0.1
A0.2
A0.3
A0.4
A0.5
A0.6
A0.7
1 A1.0
A1.1
A1.2
A1.3
A1.4
A1.5
A1.6
A1.7
2 A2.0
A2.1
A2.2
A2.3
A2.4
A2.5
A2.6
A2.7
3 A3.0
A3.1
A3.2
A3.3
A3.4
A3.5
A3.6
A3.7
