Safety Instructions; Technical Features - indexa DA02 Gebrauchsanweisung

CEILING ALARM
WITH REMOTE CONTROL
DA02
OWNERS MANUAL
This manual contains important information on the use and handling of the product. Therefore,
please keep this manual for future reference. Please read this users manual before using your
Mini Alarm. Check the unit for damage. Do not operate a damaged unit.

Safety instructions

Only use the ceiling alarm and the mains adapter in dry locations and indoors.
Do not place the unit or the mains adapter in the rain or in water.
Only use a suitable and approved mains adapter. Handle the connecting cable with care.
Before drilling, check the wall for concealed electric cables.
The siren is loud! Do not switch it on near your ears. Keep it out of children's reach.
Ready to use everywhere – very easy to install
At home, in a shop or in an office, the ceiling alarm is immediately ready to use. The built-in passive
infrared motion detector (PIR) reacts to body heat. The alarm is activated as soon as somebody enters
the PIR range. The ceiling alarm can easily be switched on and off with the remote control. Use the
ceiling alarm to secure rooms. The unit is powered by batteries, but can also be powered using a mains
adapter.

Technical features

connection for
mains adapter
alarm unit
Technical features
Alarm unit DA02
Power supply:
Power consumption:
Sensor:
PIR range:
Alarm siren:
Control system:
Field of application:
Operating temperature:
green LED
red
LED
red LED
ON/OFF
button
receiver for
remote control
(battery included)
4 x C batteries (alkaline) 1,5V (LR 14) or
mains adapter 9V, min. 200 mA
(Art.Nr. 32108)
1,5 mA (stand-by), 120 mA (alarm)
Passive infrared motion detector (PIR)
360° over a diameter of approx. 6 m (mounting height 2,5 m)
piezo alarm 100 dB(A)
Infrared remote control
Use only in dry locations, protect unit from moisture and frost.
0°C – 30°C, Optimal function at room temperature (20°C). Very high or
remote control
(inner pole of the plug negative)
2 screws mounting
2 pegs
GB
