Start up
7
Before performing any type of operation, make sure that the automation is turned off and the batteries
are disconnected.
Start-up and adjustment must be performed in the following order when the automation is installed:
1. Connect the accessories, opening and safety sensors, blocking device, batteries and selector.
2. Jumper the safety contacts 1-2, 1-3, 1-4, 8-9, 8-11 on the control panel if not used.
3. Connect the mains power supply to the automation.
4. Set the following parameters:
Parameter Description
Central presence
09
sensor test
Selection of
12
opening direction
Side presence
29
sensor test
Selection of the
67
type of automation
5. Leave ajar the casing and, if there are safety sensors, check that they are in standby mode and that there are
no people or objects moving in the sensors detection area.
6. Open the cover just enough to press the LEARN button for 2 seconds, the display flashes
To enable the stroke and weight of the door wings to be acquired correctly, the acqui-sition phase
must be performed with the door wings installed.
7. Leave ajar the casing without fixing it so that the sensors remain in their working position. Free the area of
action of the sensors so that they are detected and monitored during the learning cycle.
8. The automation performs opening and closing operations.
At the end of the learning cycle, the door remains closed and the display indicates
If some parameters have not been automatically configured during the learning cycle, the door opens. The display
first indicates , and then the parameter that has not been acquired automatically, for example, if the door is
a 2-wing or 1-wing door (parameter 67). The parameters P05, P06, P67 can be configured by the installer and/or
check that there are no obstacles and friction which prevents correct learning of open position and door weight,
shown as P59, P68, P69. Remove obstacles and repeat the learning process.
1. Press the SELECT button to start to modify the parameters.
2. Press SELECT again to display the parameter value in flashing mode.
3. Select the correct value using the UP and DOWN buttons.
4. Press SELECT to confirm and program the selected value.
5. Continue to configure the other parameters that have not been acquired
6. Press LEARN/EXIT for more than 2 seconds and the display will indicate
closes and is ready for operating.
If the reopening maneuver occurs too abruptly, set parameter 49 with a value lower than the factory value
(08), example 04 - 05.
i
To read the complete manuals use the following QR codes or type the following links:
Technical manual
https://www.ditecentrematic.com/Entrematic/ditecen
trematicCOM/QR/PD/TM/DAS107PLUS_IP2282.pdf
00 = None (factory setting)
01 = Presence sensor 1 (set if a presence sensor with monitoring is installed).
02 = Presence sensor 1 and 2 (set if two presence sensors with monitoring
are installed).
00 = right hand opening for single door wing automation.
01 = left hand opening for single door wing automation and for double door
automation (factory setting).
00 = None (factory setting)
01 = Presence sensor 1 (set if a presence sensor with monitoring is installed).
02 = Presence sensor 1 and 2 (set if two presence sensors with monitoring
are installed).
00 = Automation with one door wing.
01 = Automation with two door wings.
https://www.ditecentrematic.com/Entrematic/ditecen-
trematicCOM/QR/PD/AH/Kit_DAS107PLUS_IP2283.pdf
11
Settings
.
, after 2 seconds, the door
Assembly handbook
.
EN
